Mother/Fetus Monitor FM/FHR/TOCO/NIBP/PULSE RATE Lightweight,space-saving,easy operation. Function:FHR,Fetal movement,TOCO,110mm width Recorder and NIBP can be optional. It can be connected to the obstetrical central station to construct central monitoring system. Technical Specification: FHR Use wide-angle multi-wafer fixed on buckle of belly belt. Display Range:65-210bpm Precision:≤2bpm TOCO Use light-duty Smith safety ring shape TOCO probe. Has manual initialization(20 unit)function. The measurement range of TOCO:0 unit-100unit Icon Switch Marual key style(Patient Operation):There will be a red bar icon above OP waveform when the key is pressed. FHR FHR Manual marked Other Specification Power supply :220V±22V,50Hz±1Hz Power consumption:≤80VA Alarm:Sound and light Atmospheric pressure:86-106Kpa Working condition:Ambient tempcrature:5℃-40℃ Relative humidity:≤80% Safety:Class I,Type BF
